Product Description:
Main stratigraphic distribution:
1. The Quaternary alluvial layer consists of humus soil in the upper part, with a thickness of 1.0-4.0 meters, and an alluvial gravel layer of 45-120 meters in the lower part, which is yellow brown and dense, filled with a small amount of cohesive soil. The particle size of the gravel is 2-25cm, composed of quartzite, with good roundness and a gravel content of over 70%.
2. The bedrock is limestone, with a drillability level of 5-6. The rock has a medium thick layered structure with a dip angle of 35-40 °. The basic quality level of the rock is Grade IV. The karst phenomenon is moderately developed, and the karst caves are severely dissolved. The karst caves in the rock mass are mostly filled with clay.
Features:
From bottom to top, the structure of the drilling tool comprises:
- Roller drill bit
- Variable diameter receiver
- Powder collection tube
- Stabilizer
- Drill collar
- Drill rod
- Machine mounted drill rod
Selection and Processing of Roller Drill Bit:
Drilling into gravel and limestone formations requires the use of low-toothed and large-toothed roller bits. To cut costs in today's competitive market, our company has acquired retired roller bits with high hardness from the Panjin Petroleum Drilling Team. Specifically, the expansion drill bit is a self-processed bit made from round steel. The Φ 216mm roller bit is carefully crafted, with three separate wheel arms and a total of six welds in a stepped shape at the bit's center. To ensure quality, the outer diameter is maintained at 550mm. During cutting and welding operations, the roller arm is cooled in a tank to prevent lubricating oil from burning, thereby extending its service life and reducing water well drill bit costs significantly.
Before use, it's essential to inspect the roller bit for wear, ensure smooth rotation, and check the welding quality. Regular maintenance is crucial to prolong the roller bit's lifespan.
Technical Parameters:
| Type | Tricone Drill Bit |
| Bearing | Composite Sealed Bearing |
| Kumulierte Dauer | ≥80 Hours |
| Material | Carbide |
| Showroom Location | Hebei, China |
| Dimensions Of Three Cone Drill Bits | 3-26 Inches |
| Thread | API Reg |
| Warranty | 1 Year |
| Applicable Industries | Construction Works, Energy & Mining |
| Applicable Terrain | Rocks, Pebbles, etc. |
Applications:
RuiTong Bit's TCI tricone drill bit is a versatile drilling tool that can be used in various applications and scenarios due to its high quality and durability. Here are some product application occasions and scenarios where the Tricone Roller Bits can be effectively used:
1. Oil and Gas Exploration: The TCI tricone drill bit is ideal for oil and gas exploration projects, providing efficient drilling performance in challenging geological formations.
2. Mining Operations: Roller Cone Bits are commonly used in mining operations to drill through hard rock formations with ease, making the TCI tricone drill bit a valuable tool in the mining industry.
3. Water Well Drilling: Tricone Drill Bits are well-suited for water well drilling applications, offering reliable performance and durability in various groundwater conditions.
4. Geothermal Drilling: The TCI tricone drill bit is a reliable choice for geothermal drilling projects, providing consistent performance and longevity in high-temperature environments.
5. Construction Projects: Tricone Roller Bits are used in construction projects for drilling foundation holes, providing efficient and precise drilling in various soil and rock types.
6. Environmental Monitoring Wells: Roller Cone Bits can be used in environmental monitoring well installations, offering accurate and efficient drilling in sensitive environmental areas.
7. Exploration Drilling: Tricone Drill Bits are commonly used in exploration drilling projects for mineral exploration, offering versatility and performance in different geological conditions.
Packing and Shipping:
Product Packaging for Tricone Drill Bits:
Each Tricone Drill Bit is carefully packaged in a sturdy cardboard box to ensure maximum protection during transportation.
The box includes foam inserts to prevent any damage to the drill bit and keep it secure during shipping.
Shipping Information:
We offer worldwide shipping for our Tricone Drill Bits.
All orders are processed within 1-2 business days and shipped via reliable courier services.
Customers will receive a tracking number to monitor the status of their shipment.
FAQ:
Q: What is the brand name of this tricone drill bit?
A: The brand name is RuiTong Bit.
Q: What is the model number of this tricone drill bit?
A: The model number is TCI tricone drill bit.
Q: Where is this tricone drill bit manufactured?
A: It is manufactured in Hebei, China.
Q: What certifications does this tricone drill bit have?
A: It is certified by API and ISO9001.
Q: What are the payment terms for purchasing this tricone drill bit?
A: The payment terms are T/T and L/C.
